14

1

/

4

" THREADED ROD

4 REQ.

SECURE ANGLE
IRON TO BOTTOM
OF FURNACE WITH
3 #8 x

3

/

4

" SCREWS

TYPICAL FOR 2 SUPPORTS

1" SQUARE, 1

1

/

4

" x 1

1

/

4

" x

1

/

4

" ANGLE IRON

OR UNI-STRUT MAY BE USED

(2) HEX NUTS, (2) WASHERS & (2) LOCK WASHERS
REQ. PER ROD

8" MIN FOR DOOR
REMOVAL

OUTER DOOR
ASSEMBLY

A02345

Fig. 15 -- Horizontal Unit Suspension

METHOD 2

USE (42) #8 x 3/4 SHEET

METAL SCREWS TYPICAL

FOR EACH STRAPS.THE

STRAPS SHOULD BE

VERTICAL AGAINST THE

FURNACE SIDES AND NOT

PULL AWAY FROM THE

FURNACE SIDES.

METHOD 1

FOLD ALL STRAPS UNDER

FURNACE AND SECURE WTH

(42) #8 x 3/4 SHEET METAL SCREWS

(2 SCREWS IN SIDE AND 2 SCREWS

IN BOTTOM).

A03176

Fig. 16 -- Horizontal Suspension with Straps

312A
