Bloomfield 9600 Single Cup - Manual (Page 25)

EXPLODED VIEW & PARTS LIST (continued)
23
ITEM PART NO. DESCRIPTION QTY
51 86946 DRAWER FRONT 1
52 86947 DRAWER PULL 1
53 89861 FRONT PLATE 1
54 86951 DRAWER ARM 2
55 85621 ELBOW FITTING 2
56 55487 SCREW 8-32x5/16 TR SS 12
57 86957 LOWER POD CARRIER ASSY 1
58 86847 PLATE RING UPPER 1
59 86949 SEAL RING 1
60 86956 SPRAY DISK LOWER 1
61 86844 ARM GUIDE 2
62 86972 SCREW 8-32x1/4 FH SS 2
63 86978 SCREW 8x1 PH HI-LO 9
64 86848 DRAWER GLIDE RIGHT 1
65 86852 DRAWER GLIDE LEFT 1
66 SCREW 4-40x5/8 4
67 50198 SWITCH 2
68 86849 DRAWER CARRIER 1
69 89858 SWING ARM LEFT 1
70 86851 SWING ARM RIGHT 1
71 86980 COTTER PIN .06Dx.5 SS 2
72 86977 PIVOT ROD 1
73 86974 BEARING THRUST 2
74 SPRING 1
75 86970 O-RING 2-039 1
ITEM PART NO. DESCRIPTION QTY
76 86846 RING PLATE LOWER 1
77 86843 LIFT PLATE 1
78 86966 BEARING POD CARRIER 2
79 86842 UPPER POD CARRIER 1
80 86845 LEVER ARM 1
81 86887 ROD SPACER 2
82 86979 SCREW 8x3/8 BLK OX 5
83 57725 SCREW 8Bx1/4 PH 6
84 87074 SPACER BLOCK 1
85 85888 SPACER NYLON 4
86 87182 SPACER KEY 2
87 87091 NEEDLE BEARING 4
88 83457 NUT KEPS 8-32 SS 4
89 87086 HINGE PLATE 2
90 87087 DRAWER ARM FRONT 2
91 87090 FLAG 2
92 87089 KEY 2
93 80146 NUT HEX 4-4– SS 4
94 87194 STOP POD ROTATION 2
95 87186 SPRAY DISK UPPER 1
96 87197 O-RING 2-110 2
97 87211 KNOB, LEVER 1
98
99
100
