EXPLODED VIEW & PARTS LIST (continued)
21
ITEM PART NO. DESCRIPTION QTY
1 (page 22) BREW DRAWER ASSY 1
2
87136 UPPER HOUSING, LEFT 1
87175 UPPER HOUSING, CENTER 2
87137 UPPER HOUSING, RIGHT 1
3 86976 COVER, TOP 1
4 86975 LOWER HOUSING 1
5 86982 BASE ASSY 1
6 81732 LEG, LEVELING 4
7 CORD & CAP, NEMA 5-15P 1
8 86618 STRAIN RELIEF 1
9 84382 SWITCH, ON/OFF 1
10 84427 SOLENOID SINGLE 1.0 GPM 1
11 85089 SOLENOID ACCESS DOOR 1
12 86280 THERMOSTAT (COTHERM) 1
13 86963 PUMP, HOT WATER 12VDC 1
14 50198 SWITCH, POD BIN 1
15 87196 CONTROL BOARD 1
16 86969 BRACKET, VALVE MOUNTING 2
17 83388 VALVE, WATER OUTLET 2
18 8043-5 STRAP, TANK HOLD-DOWN 1
19 8706-20 VENT TUBE LONG 1
20 8043-83 HI-LIMIT THERMOSTAT 1
21 87172 TUBE, FILL 1
22 83521 PROBE, WATER LEVEL 1
23 82390 GROMMET, 3/8 1
24 83532 SLEEVE, PROBE 1
ITEM PART NO. DESCRIPTION QTY
25 86968 TANK COVER 1
26 8043-12 GASKET, TANK COVER 1
27 8043-14 HEATING ELEMENT, 1500W 120V 1
28 8043-30 SEAL, HEATING ELEMENT 2
29 8043-28 NUT, 1/2-20 BRASS ELEMENT 2
30 86984 WATER TANK ASSY 1
31 86962 OVERLAY KEYPAD 1
32 8718-31 LIGHT PILOT GREEN 120V 2
33 87193 TUBING, STA-PURE 1
34 86959 BYPASS SPOUT ASSY 1
35 87178 LATCH MAGNETIC 1
36 86952 POD DRAWER 1
37 86958 CUP GRID 1
38 86895 GRID, DRIP TRAY 1
39 86895 DRIP TRAY 1
40 86964 PUSH SWITCH, 120V HOT WATER 1
41 86967 HOUSING, HOPPER 1
HARDWARE NOT SHOWN
42 3-100 SCREW 8-32x1/4 PH SS 2
43 87190 SCREW #6 PH BLACK 4
44 86979 SCREW 8-32x3/8 HI-LO PH SS 14
45 83457 NUT 8-32 HEX KEPS SS 7
46
47
48
49
