Bloomfield SS2 Series - Manual (Page 5)

FEATURES AND OPERATING CONTROLS (continued)
Brewer
Adjustable Legs
Brewing Controls
Connector
Digital Readout
Bypass Nozzle
Hot Water Faucet
Nameplate
Power Key
Power Switch
Brew Chamber
Brew Chamber
Wire Rack
Satellite
Brew-Thru Lid
Connector
Handles
Nameplate
Serving Faucet
Sight Glass
Drip Tray (optional)
Allows brewer to be leveled. Also allow clearance for cleaning
underneath brewer.
Start or stop brew and select brew volume. Right and left section
are independent. Also, used to program brewer in programming
mode.
Connects to satellite. Allows satellite heater to be energized.
Allows brewer to sense that a satellite is in place.
Displays information pertaining to brew cycle and status.
Displays programming information in programming mode.
Dilution water flows into satellite from here.
Hot water dispensed here. Mounted in base on FB models.
Lists manufacturer, model and serial number.
Also lists voltage and wattage rating of brewer.
Controls brewer ON MODE and OFF MODE.
Located on lower right rear of brewer. Turns main power to
brewer ON or OFF .
Holds coffee grounds during brew cycle.
Holds paper filter and coffee grounds in proper position in brew
chamber.
Allows entry of brewed coffee and dilution water into satellite.
Minimizes splashing in the event satellite is tipped.
Connects to brewer. Allows heater to be energized. Allows
brewer to sense that a satellite is in place.
Allow the satellite to be safely carried.
Lists manufacturer, model and serial number.
Also lists voltage and wattage rating of satellite.
Fresh coffee dispensed from satellite here.
Check the level of coffee remaining here.
Optional drip tray catches drips and spills from serving faucet.
Easily removed for cleaning.
