Black Box AV200 User Manual
Page 14
Adapter Configuration
Corinex AV200 CableLAN Adapter
12
PHY Status
Notches
Indicates whether or not frequency
notches are enabled. notches should
always be enabled, in order to eliminate
interference with Radio Amateur bands
specified by the local authorities.
Power Control
Indicates status of the power control
mechanism (described in chapter
3.4.4).
Multicast Status
IGMP Aware Multicast Syndication
Shows the status of the IGMP settings
(described in chapter 3.4.5).
Multicast Bindings
Shows all multicast bindings between
multicast IP Addresses and AV200
CableLAN MAC addresses.
VLAN Status
VLAN Configuration
Indicates whether or not VLAN (virtual
networking) is enabled.
VLAN Tag
Shows the selected VLAN Tag. All traffic
from the ethernet port carries this tag.
VLAN Priority
Shows the selected priority, which is
inserted into the VLAN tag.
