Page 10
8
Installation
Corinex AV200 CableLAN Adapter
2.5
Connecting the AV200 CableLAN Adapter
To connect the Corinex AV200 CableLAN Adapter to your computer, follow the steps
listed below.
1. Connect the supplied Ethernet cable to the Ethernet (LAN) port on the
adapter and to an Ethernet port on your computer.
2.
Plug the Corinex AV200 CableLAN Adapter unit directly
into any standard electrical outlet.
Note: Please use a standard Ethernet cable for connection of the AV200
CableLAN Adapter to your computer. If you are connecting the AV200
CableLAN Adapter to a modem or switch, please use a crossover cable.
