DS72 HOST MODULE OWNER’S MANUAL
DETAILED OPERATION AND CONFIGURATION
21
Enter the desired Unit ID, followed by The DS72 module stores the
changes in non-volatile memory and returns to the configuration menu.
STATUS From the main menu, type “S” to select “Status,” followed by . The
following menu appears:
DS-72 Status Menu.
Enter selection, CR to exit.
1)...System
2)...Network Interface
3)...Logged Users
Enter Request :
SYSTEM Select “1” to display the System Status:
System Status:
Available local memory (256 byte buffers): 21
TCP sockets in use: 1
System up time (hh:mm:ss): 00:04:27
NETWORK Select “2” to display the Network Status:
Network Status:
Medium status: good
Medium faults: 0
Xmit bufr errs: 0
Available send buffers: 11
Receive queue status: open
LOGGED USERS Select “3” to display the Logged Users:
Active Users:
User Address Internal Conn Status
1 * 200.4.2.52 +
I/O MODULES RESET From the main menu, type “RM” to select “I/O Modules Reset,” followed
by . The DS72 module recycles power to all I/O ports on all
peripheral modules and responds:
I/O Modules Reset Successfully. Strike CR to Continue
UNIT RESET
NOTE: Resetting the unit does not return user selections to their default settings.
Use the menu driven selection or the ASCII character string method to
reset the DS-Series Unit:
Menu From the main menu, type “RU” to select “Reset Unit,” followed by
Driven . The DS72 module resets the unit and responds:
Selection
Reset Unit……
