DS72 HOST MODULE OWNER’S MANUAL

DETAILED OPERATION AND CONFIGURATION

DS72 CONFIGURATION If you are using the Menu Selection Method, select C, “Configure,”

followed by from the DS72 Main Menu. The following selection
menu appears:

Configuration
Module 1........................1
Module 2........................2
Module 3........................3
Select Port.....................S
Exit............................X,CR

Enter request:

If you are using the ASCII Character String Method, exit the main menu,
then select the module to configure. To select Module #1, type $BT1.
The DS72 responds “Requested Connection Made.” Send the ASCII
configuration command $CONFIG. The configuration menu appears.

Enter the number of the module to configure, followed by . To
configure the host module 1, select #1. The following configuration menu
appears for the DS72:

Status..........................1
Serial Port Configuration.......2
Port Device Name................3
Port Select Code................4
Attention Character.............5
Disconnect Timeguard............6
Connect Port ID Echo............7
Login Setup.....................8
Network Port Configuration......9
Unit ID.........................10
Configure Another Module........11
Exit............................X,CR

Enter Request:

STATUS View the status of most user programmable features by selecting #1,

“Status,” from the configuration menu, followed by . The following
menu appears:

Installed Modules :
Port Select Code is.............$BT
Attention Character is .........;
Disconnect Time Guard is........Enabled
Port ID Echo is.................Device Name
Unit ID is......................BAYTECH DS72

Network Setup :
Ethernet Address................00.C0.48.06.1A.81
IP Address......................200.4.2.65
Subnet Mask.....................255.255.255.0
Gateway.........................200.4.2.1
Inactivity Timeout (mins).......1
Break Length (msecs)............350
