Setting Up the Machine
6
6
Installing the ink cartridge
Warning
If ink gets in your eyes, wash them out with water
at once, and if irritation occurs consult a doctor.
1
Make sure that the power is turned on.
The LCD shows:
No Cartridge
2
Open the ink cartridge cover (1).
3
Pull the lock release lever down and remove
the yellow protective part (1).
Note
Do not throw away the yellow protective part. You
will need it if you transport the machine.
4
Take out the ink cartridge.
5
Carefully remove the protective yellow cap (1).
Improper Setup
DO NOT touch the area shown in the
illustration below.
Note
If the protective yellow cap comes off when you
open the bag, the cartridge will not be damaged.
1
1
1
