Rev. 1.05 - 21 -
SRP-270
[Diagram 1] Switch Functions When Using a Serial Interface (RS232C & RS485)
[Dip Switch 1 Settings]
Switch Function On Off Default
SW1-1 Off
SW1-2
Emulation Selection Refer to Chart (1) below.
Off
SW1-3 Auto Cutter Selection Enable Disable On
SW1-4 Font Interval Selection 2 3 Off
SW1-5 -
SW1-6 -
SW1-7
Service Technician Mode
Off
SW1-8 Korean Type Selection Unified Complete Off
Chart (1) Emulation Mode Selection
SW1–1 SW1-2 Mode
Off Off BXL/POS
Off On CITIZEN
On Off STAR
[Dip Switch 2 Settings]
Switch Function On Off Default
SW2-1
Auto Line Feed Selection
Always
Enable
Always
Disable
Off
SW2-2 Hexa-Printing Selection Enable Disable Off
SW2-3 Handshaking Selection On/Off DTR/DSR Off
SW2-4 Word Length Selection 7 Bit 8 Bit Off
SW2-5 Parity Check Selection Enable Disable Off
SW2-6 Parity Selection Even Odd Off
SW2-7 Off
SW2-8
Baud Rate Selection Refer to Chart (2) below.
Off
Chart (2) Baud Rate Selection
Baud Rate SW2–7 SW2–8
19200 On On
2400 Off On
4800 On Off
9600 Off Off
