ASSEMBLY INSTRUCTIONS
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING OR OPERATING YOUR GRILL.
WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN ASSEMBLING THIS UNIT.
The following provided tools are required to assemble this Grill:
• Flathead Screwdriver
• Hex Nut Wrench
PARTS LIST:
1 Right Side Table
1 Left Side Table Front Panel
1 Control Panel
1 Right Side Table Front Panel
1 Front Panel
1 Ash Cup
1 Axle with M10 Lock Nuts
2 Wheels
2 Hubcaps
4 Hood/Grill Body Hinges
1 Hood Handle
1 Thermometer
1 Hood
1 Warming Rack
1 Cooking Grill
1 Grill Body Assembly
1 Left Side Table
1 Left Leg Frame
1 Back Panel
1 Height Adjustment Knob
1 Right Leg Frame
