Brinkmann, Step 15 – Brinkmann Charcoal Grill User Manual
Page 13
12
CHARCOAL GRATE
HEIGHT ADJUSTMENT
FOR ASSISTANCE,
CALL 800-527-0717
www.grillpartsonline.com
FOR OUTDOOR
USE ONLY
Brinkmann
®
3100 Charcoal Grill (Assembled)
Step 14
Place cooking grill on grill body. Slide
charcoal ash cup onto ash cup support.
Step 15
Align tabs on the housing of thermometer
with the slots in the hood, insert
thermometer and rotate thermometer to
lock in place.
Thermometer
Thermometer Hood Slots
Tabs
