Page 4
—4—
OUTDOOR SOUND: ONE-THIRD OCTAVE BAND DATA - DECIBELS
PHYSICAL DATA
* Required filter sizes shown are based on the larger of the ARI (Air Conditioning & Refrigeration Institute) rated
cooling airflow or the heating airflow velocity of 300 ft/min for throwaway type or 450 ft/min for high-capacity
type. Air filter pressure drop for non-standard filters must not exceed 0.08 in. wg.
MODEL NO.
702B
Frequency (Hz)
024
030
036
042
048
060
63
44.8
48.0
50.0
49.1
51.4
53.7
125
60.4
58.2
60.4
63.9
65.2
62.6
250
58.3
59.2
61.6
65.2
69.7
65.9
500
64.8
65.8
66.9
67.9
72.7
70.6
1000
66.9
67.7
67.8
66.7
72.9
71.6
2000
64.3
64.8
64.6
63.8
69.8
68.2
4000
59.8
61.8
60.7
60.2
65.8
65.8
8000
51.8
53.6
52.8
50.7
57.9
58.3
UNIT SIZE 702B
024
030
036
042
048
060
NOMINAL CAPACITY (ton)
2
2-1/2
3
3-1/2
4
5
OPERATING WEIGHT (lb)
270
291
299
321
326
399
COMPRESSORS
Quantity
Scroll
REFRIGERANT*
REFRIGERANT (R-410A) Quantity (lb.)
5.0
5.5
6.9
9.0
9.5
10.0
REFRIGERANT METERING DEVICE
Accurater® Piston
ORIFICE ID (in.)
.057
.057
.065
.070
.073
.086
OUTDOOR COIL
Rows—Fins/in.
Face Area (sq ft)
1—17
9.1
1—17
12.7
2—17
9.1
2—17
12.3
2—17
12.3
2—17
16.4
OUTDOOR FAN
Nominal Airflow (Cfm)
Diameter
Motor Hp (Rpm)
2350
22
1/8 (825)
2350
22
1/8 (825)
2350
22
1/8 (825)
2350
22
1/8 (825)
3300
22
1/4 (1100)
3300
22
1/4 (1100)
OUTDOOR COIL
Rows—Fins/in.
Face Area (sq ft)
3—15
3.7
3—15
3.7
3—15
3.7
3—15
4.7
4—15
4.7
4—15
4.7
INDOOR BLOWER STANDARD
Nominal Airflow (Cfm)
Size (in.)
Motor (Hp)
800
10 x 10
1/4
1000
10 x 10
1/4
1200
10 x 10
1/2
1400
11 x 10
3/4
1600
11 x 10
3/4
1750
11 x 10
1.0
EVAPORATOR BLOWER ICM FIOP ONLY
Nominal Airflow (Cfm)
Size (in.)
Motor (Hp)
800
10 x 10
1/2
1000
10 x 10
1/2
1200
10 x 10
3/4
1400
11 x 10
3/4
1600
11 x 10
3/4
1750
11 x 10
1.0
HIGH-PRESSURE SWITCH (psig)
Cutout
Reset (Auto.)
610 ± 15
420 ± 25
LOSS-OF-CHARGE/LOW-PRESSURE SWITCH
(Liquid Line) (psig)
Cutout
Reset (Auto.)
20 ± 5
45 ± 10
RETURN-AIR FILTERS (In.)*
Throwaway
20 x 20 x 1
20 x 20 x 1
20 x 24 x 1
24 x 30 x 1
24 x 30 x 1
24 x 30 x 1
