Baby Trend DOUBLE SNAP N GO 1304TW User Manual

Page 3

ASSEMBLY:

• Remove stroller from box. The front wheels, rear wheels, parent tray, and support

bars specific to your infant car seats need to be installed prior to use.

• To attach the front wheels, unfold stroller as described in the section following.

See figure 1.

Lean the stroller backwards so that it rests on the handle and rear frame tubes and

the front wheel tubes are pointing upward.

Position the front wheel assembly at the front tube such that the large hole in the

swivel assembly will slide onto the front tube. Push each front wheel assembly

onto the front tube being careful that wheel assembly locks onto the front leg.

Pull on the wheel assembly to ensure that it is securely attached to the stroller.

Please see figure 2.

• Lean the stroller forward to rest on the front wheels. To attach the rear wheels,

position the rear axle and wheel assembly such that the brake levers are facing to

the rear of the stroller. Press the rear wheel assembly onto the rear frame tubes

being careful that the push buttons on the forward side of each rear tube engage

the hole on the forward side of each rear wheel housing. Pull on the rear wheel

assembly to ensure that it is securely attached to the stroller. Please see

figure 3a.

Ensure that the wheels are firmly locked into place. Do Not use the stroller if

the wheels are not locked into place, but rather contact our customer service

department immediately at (800) 328-7363, between the hours of 8:00am and 4:

30pm PCT, for assistance

• To attach the storage basket, slide the U-shaped basket tube into the tubes at the

rear of the stroller. Push the tube in until the snap button pops through the hole

on the female tube. Please see figure 3b.

• To attach the parent tray, position the tray so that the warning statement on the

inside can be read from the normal position of pushing the stroller. Push the

tray male end fittings into the

plastic female fittings on the

inside of the stroller handle.

Check that the tray is securely

latched in place. Please see

figure 4. To remove parent

tray, pull upward on the tray.

Stroller

Front Wheels

Rear Wheels

Parent Tray

Screws

TO ENSURE SAFE OPERATION OF YOUR STROLLER, PLEASE FOLLOW THESE

INSTRUCTIONS CAREFULLY. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.

Fig. 1

Fig. 2

Fig. 3a

Fig. 5

Fig. 6

Fig. 4

Fig. 3b
