Baby Trend DOUBLE SNAP N GO 1304TW User Manual

Page 10

Installation Instructions for Evenflo

Cozy Carry

The Double Snap-N-Go

will accommodate the new Evenflo

Cozy

Carry Infant Car Seat. Please follow the following instructions for proper

installation of the Cozy Carry.

Front Seat:

1. Remove (unscrew) Crossbars A1, B1, C, and D from the

Double Snap-N-

frame. Retain the screws you remove.

2. Attach Crossbar C to the

Double Snap-N-Go

frame using the two holes

labeled #4 as shown in figure 1. Use the two screws that you removed

in step 1.

3. Attach Crossbar D, so that the bent section faces down, to the

Double

Snap-N-Go

frame using the two holes labeled #5 as shown in figure 1.

Use the two screws that you removed in step 1.

Rear Seat:

1. Remove (unscrew) Crossbars A2, B2, and B1 from the

Double Snap-N-

frame. Retain the screws you remove.

2. Attach Crossbar B2 to the

Double Snap-N-Go

frame using the two holes

labeled #2 as shown in figure 2. Use the two screws that you removed

in step 1.

3. Attach Crossbar B1, so that the bent section faces down, to the

Double

Snap-N-Go

frame using the two holes labeled #4 as shown in figure 1.

Use the two screws that you removed in step 1.

Insertion of the Evenflo

Cozy Carry Infant Car Seat

1. With one hand grasp the car seat handle (in its upright, carrying position)

and gently place the seat, so that the baby faces the rear of the

Double

Snap-N-Go

, onto the

Double Snap-N-Go

so that the large groove on the

seat bottom, nearest the head-end of the seat, hooks over Crossbar C1

in the front or crossbar B2 in the rear. Check that the seat locked onto

the Crossbar. See Figure 3.

FOR SAFE OPERATION, IT IS VERY

IMPORTANT THAT THE SEAT LOCK SECURELY ONTO THE

CROSSBAR.

2. Loop the two ends of the Car Seat Strap (attached to the

Double Snap-

N-Go

frame) over the car seat, half way between the handle and the

foot-end of the seat, and snap the two buckles together (see Figure 4).

The first time your do this, you will need to adjust the length of the strap

for a tight fit around the car seat.

FOR SAFE OPERATION, IT IS

VERY IMPORTANT THAT THE CAR SEAT STRAP IS ALWAYS

TIGHTLY FASTENED OVER THE CAR SEAT.

3. Test for secure installation by moving the car seat in all directions. The

car seat should be securely attached to the

Double Snap-N-Go

Removal of the Evenflo

Cozy Carry Infant Car Seat

1. Unlock the Car Seat Strap and remove from over the infant car seat.

2. With one hand, grasp the car seat handle (in its upright, carrying position)

and with your other hand squeeze the red handle on the back of the car

seat and lift the car seat upward from the

Double Snap-N-Go

frame.

See Figure 5.

Bar C

Hole #4

Hole #6

Strap

Bar D-down

Hole #5

Hole #2

Hole #4

Hole #5

Strap

Bar B2

Bar B1

Fig. 1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Evenflo

and Cozy Carry

are the trademarks of their owners. They are not

associated with Baby Trend and no approval or endorsement is implied.
