11
ṇ
Kitchen fumes are best eliminated by:
q Switching ON the fan
when you start cooking.
q Switching OFF the fan
several minutes after you finish cooking.
Switching ON the fan:
1.
Pull out the filter drawer by the handle.
q
The fan is now operating.
2. Select the desired fan setting.
Controls on the various models:
Operating the extractor hood
Light:
Note: the light can be used at any time,
even if the filter drawer has been pushed in.
0
Setting 3
Setting 1
Setting 2
OFF
ON
Setting 1
Setting 2
Setting 3
Setting 1
OFF
Setting 2
Switching OFF the fan:
q
Push in the filter drawer all the way.
Note:
If the filter drawer is pulled out again,
the fan starts operating at the last selected
setting.
2
2
3 2
2
1
0
2
3
1
If you encounter a problem
If you have any questions or if a fault
occurs, please call Customer Service.
(See list of Customer Service
representatives).
When you call, please quote the following:
E-Nr. FD
Enter the relevant numbers into the box
above. The E-Nr. (product no.) and FD
(production date) are shown on the
nameplate which can be seen inside the
extractor hood after the filter frame has
been detached.
Removing and installing the filter
frames
Removal:
1.
Pull out the filter drawer all the way.
2.
Press the detents on the filter frames all
the way in the direction of the arrow.
Filters and maintenance
Filters and maintenance
Metal-mesh grease filters have been
installed to filter grease particles out of
the kitchen fumes.
The filter mats are made of incombustible
metal.
Attention:
As grease accumulates in the filter, there is
an increased risk of the filter catching fire
and the extractor hood may malfunction.
Important:
By cleaning the metal grease filters at
appropriate intervals, the possibility of them
catching fire as a result of a build-up of heat
such as occurs when deep-fat frying or
roasting is taking place, is reduced.
Cleaning the metal-mesh grease filters:
During normal operation (1 to 2 hours daily),
the metal-mesh grease filters should be
cleaned every 8 – 10 weeks.
q
The filters can be cleaned in the
dishwasher.
However, the filters may be slightly
discoloured.
Important:
If the metal-mesh grease filters are very
dirty, do NOT wash them in the
dishwasher with other pots and pans.
q When cleaning by hand, soak the filter
mats for several hours in a hot soap
solution.
Then brush them off, rinse thoroughly
and allow to drip dry.
q To ensure the best possible results,
use only original filters.
q If there are two grease filters, remove
the front one first.
3.
Fold the filter frame down at the side and
remove.
Installation:
1.
Pull out the filter drawer all the way.
2.
Insert the filter frame at an angle into the
holder, fold up and attach by pressing
the detent all the way.
q If there are two grease filters, first
insert the rear filter frame and then the
front filter frame (profiled edge) into the
filter drawer.
ṇ
Ensure that the grease filters are
securely positioned on both sides.
Activated carbon filter:
For filtering odours during circulating-air
mode.
The activated carbon filter is installed above
the grease filter(s) in the extractor hood.
1.
Remove the grease filter(s) (see Filters
and maintenance).
2.
Insert the two enclosed plastic holders
into the right and left sides of the
extractor-hood housing and attach each
holder with a screw (required only if
installing an activated carbon filter for the
first time).
