1.2 Features

Express Internet Access – ADSL2/2+ capable

The BiPAC 7300GX complies with ADSL worldwide standards. Supporting downstream

rates of 8Mbps with ADSL, the router is capable of up to 12/24 Mbps with ADSL2/2+, and

upstream rates of up to 1 Mbps. Users enjoy not only high-speed ADSL services but also

broadband multimedia applications such as interactive gaming, video streaming and

real-time audio which are easier and faster than ever. The router is compliant with

Multi-Mode standard (ANSI T1.413, Issue 2; G.dmt (ITU G.992.1); G.hs (ITU G994.1);

G.dmt.bis (ITU G.992.3); and G.dmt.bisplus (ITU G.992.5)

Communication Diversity with HSDPA/UMTS

Including one PC card slot, the BiPAC 7300GX router allows the users to insert a

3G/HSDPA PC card to share 3G/HSDPA, UMTS, EDGE, GPRS, or GSM Internet

connection.

802.11g Wireless AP with WPA Support

With integrated 802.11g Wireless Access Point in the router, the device offers a quick and

easy access among wired network, wireless network and broadband connection (ADSL)

with single device simplicity, and as a result, mobility to the users. In addition to 54 Mbps

802.11g data rate, it also interoperates backward with existing 802.11b equipment. The

Wireless Protected Access (WPA) and Wireless Encryption Protocol (WEP) supported

features enhance the security level of data protection and access control via Wireless LAN.

Fast Ethernet Switch

A 4-port 10/100Mbps fast Ethernet switch is built-in with automatic switching between MDI

and MDI-X for 10Base-T and 100Base-TX ports, with auto detection allowing you to use

either straight or cross-over Ethernet cables.

Multi-Protocol to Establish a Connection

The router supports PPPoA (RFC 2364 - PPP over ATM Adaptation Layer 5), RFC 1483

encapsulation over ATM (bridged or routed), PPP over Ethernet (RFC 2516) to establish a

connection with an ISP. The router also supports VC-based and LLC-based multiplexing.
