User’s Manual
2-9
PORTÉGÉ M780
Ultra Slim Bay
Refer to the
section in this chapter for
details.
Ultra Slim Bay latch
Slide the latch to release or secure the Ultra Slim
Bay latch.
Be sure to lock the Ultra Slim Bay latch before you transport or carry the
computer.
Ultra Slim Bay lock
screw (lock position)
Lock position is used to lock the Ultra Slim Bay
Latch.
The Ultra Slim Bay Latch is locked by securing
the Ultra Slim Bay Lock screw into the lock
position.
Ultra Slim Bay lock
screw (unlock
position)
Unlock position is used for changing the Ultra
Slim Bay. To unlock the Ultra Slim Bay latch,
please move the Ultra Slim Bay Lock screw to
unlock position.
For more information on how to remove or insert,
please refer to the
in Chapter 4.
Reserve Pen
Reserve Pen is contained in the Reserve Pen
case of Underside. Reserve Pen enables data
entry directly through display screen. Some
models are equipped with a Reserve Pen. Refer
to the
