4-4 User’s Manual
PORTÉGÉ M780
Removing the Tablet PC Pen
To remove the Tablet PC Pen, follow the steps as described below:
1. Push the Tablet PC Pen in the Tablet PC Pen slot, so that it protrudes
slightly.
2. Pull the Tablet PC Pen to remove it from the Tablet PC Pen slot.
Figure 4-3 Removing the Tablet PC Pen
Inserting the Tablet PC Pen
The Tablet PC Pen is included in the small case coming with the product.
Remove the Tablet PC Pen from small case and install it to the computer as
follows:
1. Insert the Tablet PC Pen into the Tablet PC Pen slot until it clicks.
Figure 4-4 Inserting the Tablet PC Pen
1. Tablet PC Pen slot 2. Tablet PC Pen
1
2
The Tablet PC Pen and the Reserve Pen are different in shape. Do not
insert the Reserve Pen into the Tablet PC Pen slot.
1. Tablet PC Pen slot 2. Tablet PC Pen
1
2
