Page 29
Figure 2-5 The underside of the computer
1
2
4
3
1. Battery lock
3. Speaker*
2. Battery release latch
4. Memory module slot
* Provided with some models.
Product appearance depends on the model you purchased.
Battery lock
Slide the battery lock to release the battery pack
ready for removal.
Battery release latch
Slide and hold this latch into its "Unlock" position
in order to release the battery pack for removal.
For more detailed information on removing the
battery pack please refer to Chapter 5,
.
Speaker
Some models are equipped with a speaker on
the underside of the computer.
The speaker emits sound generated by your
software as well as audio alarms, such as low
battery condition, generated by the system.
Memory module slot
The memory module slot allows for the
installation, replacement and removal of
additional memory module.
1 GB or 2 GB memory modules can be installed
in the computer's memory slot. The actual
amount of useable system memory will be less
than the installed memory modules.
Refer to the
Chapter 3, Operating Basics.
NB520 series
User's Manual
2-6
