User’s Manual 2-4
The Grand Tour
Left side
The following figure shows the computer's left side.
The left side of the computer
1. RGB (M ONITOR ) P ORT
2. F AN V ENTS
3. U NIVERSAL S ERIAL B US (USB) P ORT
4. TV O UT P ORT
5. I .LINK (IEEE 1394) P ORT
6. M ULTIPLE D IGITAL M EDIA C ARD S LOT
7. PC C ARD S LOT
1 2 3 5 4 6 7
RGB (Monitor) Port This 15-pin port lets you connect an external
video display to the computer.
Fan Vents The fan vents help prevent the CPU from
overheating.
To prevent possible over heating of the CPU, never block the fan vent.
Universal Serial Bus
(USB) Port
The Universal Serial Bus (USB 2.0 and 1.1
compatible) port enables USB-equipped devices
such as keyboards, mice, hard drives, scanners,
and printers to be connected to the computer.
TV Out Port Connect a 4-pin S- video cable into this
connector in order to output either an NTSC or
PAL television signal.
i.LINK (IEEE 1394)
Port
This port allows you to connect an external
device, such as a digital video camera, for high-
speed data transfer.
Multiple Digital
Media Card Slot
The Multiple Digital Media Card Slot allows you
use media cards from digital still cameras and
other various forms of portable information
equipment.
PC Card Slot The PC Card slot can accommodate one 5 mm
PC Card (Type II). You can install any industry
standard PC Card such as a SCSI adapter,
Ethernet adapter or flash memory card.
