6

MiniCAFS 2.1A Operating Manual
GP/211/05 Issue 2. April 2005

©Hale Products Europe. Our policy is one of continuous development. We therefore
reserve the right to amend specifications without notice or obligation.


GENERAL DATA

ENGINE
Manufacture

Briggs

&

Stratton

Model 18HP

Vanguard

Bore

&

Stroke

72.5mm

x

70mm

Capacity

570

cc

Number of cylinders

2 cyl vee

Number of main bearings

2

Lubrication Pressurised

Full Flow System

Service Oil Fill Capacity

1.7 litres

Oil

filter

'Spin

On'

disposable

canister

Fuel

feed

Vacuum

Pulse

Pump

Fuel

tank

capacity

8.5

litres

Battery

12v/14A




COMPRESSOR
Model HSC50
Maximum Operating Speed

7250 rpm

Nominal speed of operation

6250 rpm

Nominal

power

draw

12.0kW

Direction

of

rotation

Anti-clockwise

(when looking on pulley)
Oil volume (approximate)

3.5 litres



FOAM PROPORTIONING SYSTEM
Manufacturer

Hale

Products

Inc

Model Foamlogix

2.1A

Type

Electronic Foam Proportioning system

Operating

voltage

12

volts

Current

draw

20

amp

Max. Foam Agent Flowrate

8.0 L/Min
