Connecting the units – Pioneer DEX-P99RS User Manual
Page 5
5
English
High/Mid/Low/Subwoofer output
20 cm
1.5 m
Fuse resistor
Blue/white (SYSTEM REMOTE CONTROL)
Connect to system control terminal of the
power amp or auto-antenna relay control
terminal (max. 300 mA 12 V DC).
IP-BUS input (Blue)
This product
Wired remote input
Hard-wired remote control adaptor
can be connected (sold separately).
USB cable
Connect to separately sold USB device.
USB input jack
Connecting the units
