Connecting rca audio and video output, Installation, Connecting the system – Pioneer AVD-W8000 User Manual
Page 32
31
Connecting RCA Audio and Video Output
Connecting the System
Power cable
(Refer to page
28)
Hide-away Unit
RCA AUDIO OUTPUT
(white, red)
RCA VIDEO OUTPUT
(yellow)
Commercial RCA video
cable (yellow)
Commercial RCA audio
cable (white, red)
To AUDIO INPUT
(R)
To AUDIO INPUT
(L)
To VIDEO INPUT
Second display,
video deck, etc.
15 cm
Sold separately
