1 Press M.C. to display the setting mode.

2 Turn M.C. to adjust the left/right speaker bal-

ance.

EQ SETTING (equalizer recall)

1 Press M.C. to display the setting mode.

2 Turn M.C. to select the equalizer.

POWERFUL

—NATURAL—VOCAL—CUS-

TOM1

—CUSTOM2—FLAT—SUPER BASS

The equalizer band and equalizer level can be
customized when

CUSTOM1 or CUSTOM2 is

selected.
If selecting

CUSTOM1 or CUSTOM2, complete

the procedures outlined below. If selecting
other options, press

M.C. to return to the pre-

vious display.
! CUSTOM1 can be set separately for each

source. However, each of the below combi-
nations are set to the same setting auto-
matically.
! USB, iPod, PANDORA (iPhone), and

APP (iPhone)

! BT AUDIO, PANDORA (smartphone),

and

APP (smartphone)

! CUSTOM2 is a shared setting used in com-

mon for all sources.

3 Press M.C. to display the setting mode.
4 Press M.C. to cycle between the following:

Equalizer band

—Equalizer level

5 Turn M.C. to select the desired setting.

Equalizer band:

80HZ

—250HZ—800HZ—

2.5KHZ

—8KHZ

Equalizer level:

+6 to

–6

LOUDNESS (loudness)

Loudness compensates for deficiencies in the low-
frequency and high-frequency ranges at low vol-
ume.
1 Press M.C. to select the desired setting.

OFF (off)

—LOW (low)—MID (mid)—HI (high)

SUB.W (subwoofer on/off setting)

This unit is equipped with a subwoofer output
which can be turned on or off.
1 Press M.C. to select the desired setting.

NOR (normal phase)

—REV (reverse phase)—

OFF (subwoofer off)

SUB.W CTRL (subwoofer adjustment)

Only frequencies lower than those in the selected
range are outputted from the subwoofer.
1 Press M.C. to display the setting mode.

2 Press M.C. to cycle between the following:

Cut-off frequency

—Output level—Slope level

Rates that can be adjusted will flash.

3 Turn M.C. to select the desired setting.

Cut-off frequency:

50HZ

—63HZ—80HZ—

100HZ

—125HZ—160HZ—200HZ

Output level:

–24 to +6

Slope level:

–12— –24

BASS BOOST (bass boost)

1 Press M.C. to display the setting mode.
2 Turn M.C. to select a desired level.

0 to +6 is displayed as the level is increased or
decreased.

HPF SETTING (high pass filter adjustment)

Use this function when wanting to listen only to
high-frequency sounds. Only frequencies higher
than the high-pass filter (HPF) cutoff are output
from the speakers.
1 Press M.C. to display the setting mode.
2 Press M.C. to cycle between the following:

Cut-off frequency

—Slope level

3 Turn M.C. to select the desired setting.

Cut-off frequency:

OFF

—50HZ—63HZ—80HZ

—100HZ—125HZ—160HZ—200HZ
Slope level:

–12— –24

SLA (source level adjustment)

This function prevents the volume from changing
too dramatically when the source switches.
! Settings are based on the FM volume level,

which remains unchanged.

! The MW volume level can also be adjusted

with this function.

! Each of the below combinations are set to the

same setting automatically.
! USB, iPod, PANDORA (iPhone), and APP

(iPhone)

! BT AUDIO, PANDORA (smartphone), and

APP (smartphone)

1 Press M.C. to display the setting mode.
2 Turn M.C. to adjust the source volume.

Adjustment range:

+4 to

–4

System menu

Press M.C. to display the main menu.

Turn M.C. to change the menu option

and press to select SYSTEM.

Turn M.C. to select the system menu

function.
Once selected, the following system menu func-
tions can be adjusted.

! BT AUDIO, BT MEM CLEAR, BT VERSION

and

APP CONN. SET are not available for

MVH-X465UI.

CLOCK SET (setting the clock)

1 Press M.C. to display the setting mode.
2 Press M.C. to select the segment of the clock

display you wish to set.
Hour

—Minute

3 Turn M.C. to adjust the clock.

12H/24H (time notation)

1 Press M.C. to select the desired setting.

12H (12-hour clock)

—24H (24-hour clock)

INFO DISPLAY (sub information)

The type of text information displayed in the sub
information section can be toggled.
1 Press M.C. to display the setting mode.

2 Turn M.C. to select the desired setting.

SPEANA

—LEVEL METER—SOURCE—CLOCK

—OFF

! The signal bar indicator displays for SPEANA

LEVEL METER when the source is set to

RADIO.

AUTO PI (auto PI seek)

The unit can automatically search for a different
station with the same programming, even during
preset recall.
1 Press M.C. to turn Auto PI seek on or off.

AUX (auxiliary input)

Activate this setting when using an auxiliary de-
vice connected to this unit.
1 Press M.C. to turn AUX on or off.

DIMMER (dimmer)

1 Press M.C. to turn the dimmer on or off.

! You can also change the dimmer setting by

pressing and holding

DIMMER.

BRIGHTNESS (brightness adjustment)

You can use this setting to adjust the display
brightness.
The range of settings available for

BRIGHTNESS

will vary depending on whether

DIMMER is on or

off. For details, refer to

DIMMER (dimmer) on page

13.
1 Press M.C. to display the setting mode.

2 Turn M.C. to select the desired setting.

DIMMER on: 1 to 4
DIMMER off: 1 to 5

BT AUDIO (Bluetooth audio activation)
