Audio adjustments
1
Press M.C. to display the main menu.
2
Turn M.C. to change the menu option
and press to select AUDIO.
3
Turn M.C. to select the audio function.
Once selected, the following audio functions
can be adjusted.
! FADER is not available when
SUB.W/SUB.W is selected in
SP-P/O MODE. For details, refer to
SP-P/O MODE (rear output and preout set-
ting) on page 22.
! SUB.W, SUB.W CTRL and HPF SETTING
are not available when
REAR/REAR is se-
lected in
SP-P/O MODE. For details, refer to
SP-P/O MODE (rear output and preout set-
ting) on page 22.
! SUB.W CTRL and HPF SETTING are not
available when
SUB.W is selected in OFF.
For details, refer to
FADER (fader adjustment)
1 Press M.C. to display the setting mode.
2 Turn M.C. to adjust the front/rear speaker bal-
ance.
BALANCE (balance adjustment)
1 Press M.C. to display the setting mode.
2 Turn M.C. to adjust the left/right speaker balance.
EQ SETTING (equalizer recall)
1 Press M.C. to display the setting mode.
2 Turn M.C. to select the equalizer.
POWERFUL
—NATURAL—VOCAL—CUSTOM1
—CUSTOM2—FLAT—SUPER BASS
The equalizer band and equalizer level can be cus-
tomized when
CUSTOM1 or CUSTOM2 is se-
lected.
If selecting
CUSTOM1 or CUSTOM2, complete
the procedures outlined below. If selecting other
options, press
M.C. to return to the previous dis-
play.
! CUSTOM1 can be set separately for each
source. However,
USB and iPod are all set to
the same setting automatically.
! CUSTOM2 is a shared setting used in com-
mon for all sources.
3 Press M.C. to display the setting mode.
4 Press M.C. to cycle between the following:
Equalizer band
—Equalizer level
5 Turn M.C. to select the desired setting.
Equalizer band:
80HZ
—250HZ—800HZ—2.5KHZ
—8KHZ
Equalizer level:
+6 to
–6
LOUDNESS (loudness)
Loudness compensates for deficiencies in the low-fre-
quency and high-frequency ranges at low volume.
1 Press M.C. to select the desired setting.
OFF (off)
—LOW (low)—MID (mid)—HI (high)
SUB.W (subwoofer on/off setting)
This unit is equipped with a subwoofer output which
can be turned on or off.
1 Press M.C. to select the desired setting.
NOR (normal phase)
—REV (reverse phase)—OFF
(subwoofer off)
SUB.W CTRL (subwoofer adjustment)
Only frequencies lower than those in the selected
range are outputted from the subwoofer.
1 Press M.C. to display the setting mode.
2 Press M.C. to cycle between the following:
Cut-off frequency
—Output level—Slope level
Rates that can be adjusted will flash.
3 Turn M.C. to select the desired setting.
Cut-off frequency:
50HZ
—63HZ—80HZ—100HZ
—125HZ—160HZ—200HZ
Output level:
–24 to +6
Slope level:
–6— –12
BASS BOOST (bass boost)
1 Press M.C. to display the setting mode.
2 Turn M.C. to select a desired level.
0 to +6 is displayed as the level is increased or de-
creased.
HPF SETTING (high pass filter adjustment)
