6 ESC key
Touch to cancel the control mode of func-
tions.
1 Touch Menu to display Menu.
Menu appears on the display.
# When Menu is not displayed, you can display
it by touching the screen.
2 Touch the desired key to display the
function names you want to operate.
# Touch or to switch between the lists of
names.
3 Touch ESC to return to the normal dis-
play of each mode.
Selecting a mode
You can select a mode you want to display.
% Touch Mode and then touch the desired
mode name.
There are the following five modes:
! Analog Analog mode
! Digital Digital mode
! Cyber Cyber mode
! Virtual Virtual mode
! V.Status Vehicle status mode
Analog mode
1 2 3
You can customize the gauges and the back-
ground.
! To select the different types of gauges, refer
to Selecting gauges on page 12.
! To control a peak hold function, refer to
Using a peak hold function on page 13.
! To customize the colors of gauge, refer to
Selecting the colors on page 14.
! To select the background, refer to Selecting
the background display on page 14.
1 Accelerometer (ACC.G)
Shows the acceleration in a forward direc-
tion. The + sign indicates acceleration
while the sign indicates deceleration
(braking).
2 Speedometer (SPEED)
Shows your vehicle speed.
3 Tachometer (TACH)
Shows the engine speed in revolutions per
minute (rpm).
Digital mode
1 3 4 2 5
b c 8
6
a 9 7
You can customize the gauges and the back-
ground.
! To control a peak hold function, refer to
Using a peak hold function on page 13.
! To customize the colors of gauge, refer to
Selecting the colors on page 14.
