Specifications
General
Power source .......... 14.4 V DC (10.8 – 15.1 V allowable)
Grounding system ........................................ Negative type
Max. current consumption ...................................... 11.5 A
Dimensions
(mounting size) .. 180 (W)
× 50 (H) × 155.6 (D) mm
(front face) .......... 170 (W)
× 45 (H) × 23.8 (D) mm
Weight .................................................................... 1.85 kg
Audio
Maximum power output ...................................... 50 W
× 4
50 W
× 2 ch/4 Ω + 70 W × 1 ch/2 Ω (for Subwoofer)
Continuous power output .................................... 22 W
× 4
(DIN45324, +B = 14.4 V)
Load impedance ........ 4
Ω (4 – 8 Ω [2 Ω for 1 ch] allowable)
Preout maximum output
level/output impedance .......................... 4.6 V/100
Ω
Equalizer (3-Band Parametric Equalizer)
(Low) .......................... Frequency: 40/80/100/160 Hz
Q Factor: 0.35/0.59/0.95/1.15
(+6 dB when boosted)
Gain: ±12 dB
(Mid) .......................... Frequency: 200/500/1k/2k Hz
Q Factor: 0.35/0.59/0.95/1.15
(+6 dB when boosted)
Gain: ±12 dB
(High) ................ Frequency: 3.15k/8k/10k/12.5k Hz
Q Factor: 0.35/0.59/0.95/1.15
(+6 dB when boosted)
Gain: ±12 dB
Loudness contour
(Low) .................. +3.5 dB (100 Hz), +3 dB (10 kHz)
(Mid) ................ +10 dB (100 Hz), +6.5 dB (10 kHz)
(High) ................ +11 dB (100 Hz), +11 dB (10 kHz)
(volume: –30 dB)
HPF
Frequency ............................................ 50/80/125 Hz
Slope ........................................................ –12 dB/oct.
Subwoofer
Frequency ............................................ 50/80/125 Hz
Slope ........................................................ –18 dB/oct.
Gain ................................................................ ±12 dB
Phase ................................................ Normal/Reverse
CD player
System .................................... Compact disc audio system
Usable discs .................................................. Compact disc
Signal format .................... Sampling frequency: 44.1 kHz
Number of quantization bits: 16; linear
Frequency characteristics .............. 5 – 20,000 Hz (±1 dB)
Signal-to-noise ratio ...... 96 dB (1 kHz) (IEC-A network)
Dynamic range ............................................ 94 dB (1 kHz)
Number of channels ............................................ 2 (stereo)
DAB tuner
Frequency range
(Band III) .......... 174.928 – 239.200 MHz (5A – 13F)
(L Band) .... 1,452.960 – 1,490.624 MHz (L1 – L23)
Usable sensitivity
(Band III) .................................................. –97.5 dBm
(L Band) .................................................... –100 dBm
Mode ................................................................ I, II, III, IV
FM tuner
Frequency range ...................... 87.5 – 108 MHz (50 kHz)
Usable sensitivity .................................................... 11 dBf
(1.0
µV/75 Ω, mono, S/N: 30 dB)
50 dB quieting sensitivity ........................................ 16 dBf
(1.7
µV/75 Ω, mono)
Signal-to-noise ratio ...................... 70 dB (IEC-A network)
Distortion .......................... 0.3% (at 65 dBf, 1 kHz, stereo)
Frequency response ...................... 30 – 15,000 Hz (±3 dB)
Stereo separation .......................... 40 dB (at 65 dBf, 1 kHz)
MW tuner
Frequency range ........................ 531 – 1,602 kHz (9 kHz)
Usable sensitivity .............................. 18
µV (S/N: 20 dB)
Selectivity .................................................. 50 dB (±9 kHz)
LW tuner
Frequency range ........................................ 153 – 281 kHz
Usable sensitivity .............................. 30
µV (S/N: 20 dB)
Selectivity .................................................. 50 dB (±9 kHz)
Note:
• Specifications and the design are subject to possi-
ble modification without notice due to improve-
ments.
