Example of system setup cleaning the air filter, Remove the front air filter – BOXLIGHT MP-650i User Manual
Page 31
31
RGB IN
1
2
CONTROL
RGB OUT
S-VIDEO IN
VIDEO IN
AUDIO IN
L
MONO
R
USB
AUDIO
OUT
AUDIO IN
1
2
Example of system setup
Cleaning the Air filter
Turn power off to all devices before connecting.
Refer to the instruction manual of each device before connecting.
Caution
AC input
Video tape recorder with S jack
Video tape recorder
Speaker (with built-in amp)
Display monitor
Computer
(desktop type)
Computer
(notebook type)
Clean the air filter about every 100 hours of projector use.
1
Turn off the MAIN POWER switch of the projector and
pull out the power cord.
2
Remove the front air filter.
