Advanced settings
47
En
A
5
Setting
Options
Explanation
Audio Output
DRC (Dynamic Range
Control)
Off
Select this to output audio signals without using the DRC function.
On
Select this to adjust the range between the loudest and softest sounds
(dynamic range) for playback at average volume. Use this when it is hard to
hear dialog or when watching movies at midnight.
• This affects such audio signals as Dolby Digital.
• Depending on the file, the effect may be weak.
Dual Mono
1CH
When multiple audio signals are input to TV (ARC) or an optical input, the
main audio is selected.
2CH
When multiple audio signals are input to TV (ARC) or an optical input, the sub
audio is selected.
1CH+2CH
When multiple audio signals are input to TV (ARC) or an optical input, the
main audio and sub audio are selected.
Speaker Setup
(SBX-N700 only)
Adjust the Delay (distance from viewers) of the speakers.
Please see “Adjust speaker settings” for more details (page 50).
Subwoofer Setup
(SBX-N700 only)
Wireless
Select this to use the wireless subwoofer.
Built in
Select this to use the built-in subwoofer.
HDMI
Color Space
RGB
Select this to output the video signals as RGB signals. Choose this if the
colors seem too faint and the black seems too bright.
YCbCr
Select this to output the video signals as YCbCr 4:4:4 signals.
YCbCr 422
Select this to output the video signals as YCbCr 4:2:2 signals.
Full RGB
Select this to output the video signals as RGB signals. Choose this if the
colors seem too dense and all the dark colors are displayed in a uniform
black.
Resolution
Auto
Select this to choose the resolution of the video signals output from the HDMI
OUT
terminal automatically.
480I/576I
Output the video signals from the HDMI OUT terminal with the selected
resolution.
480P/576P
720P
1080I
1080P
HDMI Audio Out
Bitstream
Select this to output HDMI audio signals directly.
PCM
Select this to output HDMI audio signals converted to PCM audio signals.
Off
Select this when you do not want to output the audio signal from the HDMI
output terminal.
HDMI Deep Color
30bits
Select this when outputting the video signals with 30-bit color.
36bits
Select this when outputting the video signals with 36-bit color.
Off
Select this when outputting the video signals with normal 24-bit color.
When [30bits] or [36bits] is selected, set the color space to a setting other than YCbCr 422.
HDMI 1080P 24Hz
On
Select this when Resolution is set to Auto or 1080P and outputting 1080p/24
video signals to a TV compatible with 1080p/24.
Off
Select this when Resolution is set to 1080P and outputting 1080p/60 video
signals to a TV compatible with 1080p/60.
Control
On
Select this to control the unit with the remote control of a TV connected with
an HDMI cable or the HDMI audio return channel (ARC). Also refer to “Control
with HDMI function” (page 44).
Off
Select this to not control the unit with the remote control of a TV connected
with an HDMI cable.
HDMI Standby Mode
On
The Control with HDMI function can be used even when the unit is in standby
mode.
Off
The Control with HDMI function cannot be used when the unit is in standby
mode.
