5
EN
Pre
par
at
ion
s
for
s
hoot
ing
Basic guide
Attaching a lens to the camera
1
2
2
1
Body cap
3
3
4
1
2
Lens cap
Alignment mark
(Red) Lens attachment mark
(Red)
2
1
Lens release button
1
Remove the body cap from the camera and the
rear cap from the lens
2
Attach a lens to the camera
• Do not touch internal portions of
the camera.
• Make sure the camera is turned off.
• Do not press the lens release
button.
3
Remove the lens cap
(
3 , 4 )
Removing the lens from the camera
While pressing the lens release button (1),
rotate the lens in the direction of the arrow
(2).
g“Interchangeable lenses” (P. 129)
• Align the lens attachment mark (red)
on the camera with the alignment
mark (red) on the lens, then insert
the lens into the camera’s body (1).
• Rotate the lens in the direction
indicated by the arrow until you hear
it click (2).
Rear cap
Lens release
button
