Igniter Cap

Battery

Cooking Grills

Heat Distribution
Plates

Grooves

Warming Rack

Step 18

Place side burner grate over side
burner.

Step 19

Place the heat distribution plates
on lower level of grill body
assembly directly above burners.

Step 20

Place cooking grills on support
ribs directly above heat
distribution plates.

Step 21

Insert warming rack into brackets
so that it sits above the cooking
grills.

Step 22

Igniter battery holder is located
under side table front panel.
Remove igniter cap and insert
battery with positive end of battery
toward igniter cap. Ensure spring is
in place inside igniter cap. Replace
igniter cap and make sure the
igniter is working properly.
