133

EN

In

fo

rm

at

io

n

11

Can be used with the optional EX-25 extension tube under the following conditions.
The focus adjustment when EX-25 is used will be MF.

„

Storage Precautions

• Clean the lens after use. Remove dust and dirt on the surface of the lens with a blower brush or

brush. Use commercially available lens cleaning paper to remove the dirt on the lens. Do not use
organic solvents.

• Always cap the lens and store it when it is not used.
• Do not store in an area with insect repellent.

x

Notes on Shooting

• Edges of pictures may be cut off if more than one filter is used or if a thick filter is used.

In the P mode, the camera is programmed such that the aperture value and shutter speed are
automatically selected according to the subject’s brightness as shown below. The program line
diagram varies with the type of lens mounted.

Lens, focal length

Shooting range

Magnification

( ): Calculated based on 35 mm film camera

14 – 42 mm

14 mm

Shooting is not possible since subjects cannot be brought into focus at this
focal length.

25 mm

13.3 cm

1.02x (2.04x)

42 mm

16.2 cm – 17.3 cm

0.61 – 0.69x (1.22 – 1.38x)

14 – 54 mm

14 mm

Shooting is not possible since subjects cannot be brought into focus at this
focal length.

54 mm

17.7 cm – 22.2 cm

0.47 – 0.65x (0.94 – 1.3x)

12 – 60 mm

12 mm

Shooting is not possible since subjects cannot be brought into focus at this
focal length.

60 mm

21 cm – 25.6 cm

0.43 – 0.58x (0.86 – 1.16x)

Program line diagram (P mode)

When using the
14 – 42 mm f3.5 – 5.6
zoom lens
(focal length: 14 mm,
ISO100)

Program shift

k

j

A

p

er

ture

va
lue

Shutter speed
