Specifications
Product Type Digital SLR Camera with 1.8 in./4.5 cm color TFT LCD monitor
Memory 3V (3.3V) SmartMedia (SSFDC) Card (2M, 4M, 8M, 16M,
32M and 64MB)
One 32MB card supplied with camera, 3V CompactFlash
Type I & II Flash Memory (Micro Drive not recommended)
Recording System Still image: JPEG (DCF: “Design rule for Camera File system”),
TIFF (non-compressed), DPOF support RAW (16 bits per
color) Ships with Photoshop plug-in for RAW 10 Bit
(A➔D) Converter
Number of storable pictures with 32MB SmartMedia card
Image Pickup Element 2/3 inch CCD solid-state image pickup 4.1 million pixels
(effective 4 million pixels), RGB Interlaced Scan
White Balance iESP full-auto TTL, 7 stage Preset Manual (3000˚; 3500˚;
4000˚; 4500˚; 5500˚; 6500˚; and 7500˚K), One-Touch Manual
Lens Olympus lens 9 - 36mm 2.0-2.4, ED and aspherical glass 4x
zoom Lens (equivalent to 35 - 140mm lens on 35mm camera),
optional 0.8x (wide) 1.45x, 3x (telephotos) and macro lenses
(aperture is 7-bladed for precise aperture shape and function)
Filter Size 62 mm
Photometric System Digital ESP multi-patterned, center-weighted and spot
metering systems
Exposure Control Programmed auto exposure, Aperture priority, Shutter priority,
+/- 2Ev by 1/3EV steps exposure compensation
Auto Bracketing: selectable from 1/3EV, 2/3 EV and 1EV; 3
or 5 images
Aperture priority: Wide; F2.0 - 11, Tele; F2.4 - 11, 1/3EV steps
Shutter priority: 2 - 1/640 sec. 1/3EV steps
Manual exposure: shutter speed bulb, 8 sec. -1/640 sec.
ISO Auto, user selectable. 80, 160, 320 equivalent ISO
Focusing Dual AF-Active (IR and Passive TTL) system autofocus
(contrast detection system) with focusing range:
8"/0.2 m -
∞
(infinity) stepless
Manual focus: with focusing screen
Working Range 8"/20 cm. –
∞
(infinity)
Viewfinder Optical SLR viewfinder (Full Information/Mode/Aperture/
Shutter Speed/Spot/Center-Weighted/ iESP/+/-/AF/Flash)
Focusing Screen (Shows Focus)
LCD Monitor 1.8 in./4.5 cm wide angle color TFT LCD monitor with
114,000 pixels (made from low-temperature poly-silicon),
brightness adjustment is possible: adjustable to 20˚, 0˚,
and 92˚ (click stops)
Flash Modes Built-in Flash: Auto-Flash (low- & back-light),
Red-Eye Reducing Flash, Off, Fill-in (Forced Activation)
Slow Synchronization (First-Curtain Synchronization
effect, Second-Curtain Synchronization effect)
Flash system uses exclusive iESP scene-detecting flash
External terminals: Hot shoe and PC Sync
Flash Working Range Wide: approx. 2'/.6 m – 20.8'/6.3 m; telephoto: approximately
1.7'/.5 m – 17.2'/5.2 m (ISO 80)
Flash Recharge Time Approximately 7 sec. (normal temperature with new battery)
Sequence Mode 3 frames per sec. up to 4 frames, 1.2 second shot to
shot or faster
TruePic Technology Available at all resolutions from SHQ-SQ
Time-Lapse Intervals 1 min. to 24 hours
Selftimer/Remote 12 second delay/2 sec. after optional remote controller
Controller (RM-1) operation
Setting Memorization Possible
Outer Connectors DC input terminal, data input/output terminal USB interface
(only), video output terminal (NTSC), external PC flash terminal
for studio strobes or PC sync strobes, 3-pin Olympus
remote cable release connector
Operating Environment Operation: 32 – 104°F, 0 – 40°C, 30 – 90%
Storage: -4 – 140°F, -20 – 60°C, 10 – 90%
Power Supply Main power source: 2 x Lithium battery CR-V3/LiPo
Battery with Optional Grip/4 x AA NiMH batteries/4 x AA
Ni-Cd batteries/Optional C7AU-AC adapter (Manganese
batteries cannot be used)
Date/Time/Calendar Adjustable with simultaneous recording onto image data
Automatic Calendar Up to year 2030
System
Dimensions 5.1 in./128.5 mm (W) x 4.1 in./103.5 mm (H) x 6.8 in./161 mm
(L) (excluding projections)
Weight 37 oz./1050 g (without batteries and SmartMedia Card)
Recording Mode No. of Frames File Size
SHQ/Non-compressed 2 2240 X 1680
RAW 7 2240 X 1680
SHQ 11 2240 X 1680 (2.7:1 JPEG)
HQ 30 2048 X 1536 (8:1 JPEG)
SHQ, HQ, SQ1 and SQ2 Resolutions include 2240 X 1680, 1600 X 1200, 1280 X 960, 1024 X 768,
640 X 480 with compressions 2.7:1, 4:1, 8:1 JPEG
E
1
0
S
L
R
Now that you’ve shot the most beauti-
ful images you ever have, what do you do
with them?
Since they’re digital, you have a variety
of options. And every one of them will do
justice to the pictures you took with the
finest, most advanced digital camera on
the face of the earth, the Olympus Camedia
E-10 SLR.
S h o w c a s e yo u r w o r k
i n a v a r i e t y o f w a y s .
The P-400 is our professional-level
printer. It prints gorgeous dot-free,
continuous-tone, dye sublimation
prints at sizes near 8" x 10." Want
rich, sharp, stunning enlargements?
The P-400 is your printer.
The E-10 accepts both SmartMedia™ and
CompactFlash™ (Types I and II) simultane-
ously, and lets you copy from card to card.
Believe it or not, you can have
portable dot-free, continuous-tone,
dye sublimation printing. The P-200
is smaller than a 5" x 7" print,
though maybe a bit thicker. And you
can print right from your E-10, with
no computer. Think of it. Beautiful
prints, anytime, anywhere.
You can playback and preview images right on your
NTSC monitor. Everyone can see what you see,
without having to crowd around the camera.
The USB SmartMedia™ Reader/Writer is handy to
leave hooked up to your computer. It downloads
pictures at a sizzling 1MB per second.
