BIOS Setup Utility SY- P4I865PE Plus DRAGON 2
69
Onboard Serial Ports
Setting Description Note
Normal Default
IrDA
ASKIR
UART Mode
Select
SCR
The second serial port offers
several special modes. It can
either work as an infrared device
(IrDA, ASKIR) or as a Smart
Card reader (SCR), or as a
normal serial port.
If [UART Mode Select] is set to [IrDA]/[ASKIR]
Half Default UR2 Duplex
Mode
Full
Choose [Half] or [Duplex] to set
UR2 in half duplex mode or full
duplex mode respectively. Refer
to your IR device specifications
to select the suitable mode.
Onboard Parallel Ports
Setting Description Note
Disabled
378/IRQ7 Default
3BC/IRQ7
Onboard Parallel
Port
278/IRQ5
Choose the printer I/O
address.
SPP Default
EPP
ECP
Parallel Port Mode
ECP+EPP
The mode depends on your
external device that
connects to this port.
If [Parallel Port Mode] is set to [ECP] mode
3 Choose DMA3 Default ECP Mode use
DMA
1 Choose DMA1
