Hardware Installation SY- P4I865PE Plus DRAGON 2
34
5. AUX-IN (AUXIN1)
This Motherboard provides one AUX-IN connectors. Please connect the
4-pin audio cable from your second CD-ROM or DVD ROM drive to either
AUX-IN.
Please install according to the following pin assignment:
6. MIC & LED Connector (J30)
You can connect the Line-out /MIC in /LAN LED to the front panel of your
PC case (If this option is available in your PC case). This connector has the
following pin assignment:
AUXIN1
Pin Assigment
Right
Left
GND
GND
1 2 3 4
(J30)
MIC & LED Connector
2
4
1
Line_Out_L Line_Out_R
GND
VCC
MIC IN
LAN_Active_LED
3
5 6
