Hardware Installation SY- P4I865PE Plus DRAGON 2
19
Step 3 Installation of Expansion Cards
The motherboard has 1 AGP slot and 5 PCI slots.
1. Read the related expansion card’s instruction document before inserting
the expansion card into the computer.
2. Press the expansion card firmly into the expansion slot in the motherboard .
3. Make sure the metal contacts on the card are seated in the slot.
4. Replace the screw to secure the slot bracket of the expansion card.
5. Install required driver for the operating system you use.
This motherboard only support 1.5V AGP card (4X/8X card). If 3.3V
AGP card is used, the system will not boot-up and the AGPDET LED
will lit.
AGP Slot
If use 3.3V AGP c a rd,the system will no t p ower on a nd the AGPDET LED will lit.
(1.5V only)
(When AGPDET LED lit, it m eans 3.3V AGP c ard is used.)
