Hardware Installation SY- P4I865PE Plus DRAGON 2
11
V
GAMEPORT connector
This connector is to attach your gameport connector to. Gameports
are used to connect for example joysticks to. For more details
check the paragraph on page 30.
W
Serial Infrared (IrDA) device header
This header allows you to connect an IrDA receiver to the
motherboard. You can find the lay-out in the 1. Standard Infrared
(SIRCON) paragraph on page 30.
X
Smart Card Reader connector
This connector allows you to connect a smart card reader to the
PC/SC, ISO 7816 compliant onboard smart card reader. The
paragraph 3. Smart Card Reader on page 33 contains more
information on the lay-out of this header.
Y
32 bit PCI slots
These are the motherboard's 3.3v busmastering PCI slots,
compliant to PCI specification v2.2.
Z
ITE IT8712F-A Super I/O Chip
The IT8712F-A is a Low Pin Count Interface-based highly
integrated Super I/O. The IT8712F-A provides the most commonly
used legacy Super I/O functionality plus the latest Environment
Control initiatives, such as H/W Monitor, Fan Speed Controller,
ITE's 'SmartGuardian' function and Smart Card Reader Interface.
The device's LPC interface complies with Intel 'LPC Interface
Specification Rev. 1.0'. The IT8712F-A meets the 'Microsoft®
PC98 & PC99 System Design Guide' requirements, and is ACPI &
LANDesk compliant.
AA
CD-IN connector
This connector is to attach your analog audio output channel from
your CDROM or DVD drive to your motherboard. Please check
the 4. CD Line-in (CDIN1) paragraph on page 33 for more details.
AB
AUX-IN connector
This connector allows you to attach a second CDROM analog
audio out output to your mainboard. Please check the 5. AUX-IN
(AUXIN1) paragraph on page 34 for more details.
