Hardware Installation SY- P4I865PE Plus DRAGON 2
39
Repeat this operation until you get the following screen.
3. The BIOS Setup screen appears:
Phoenix – Award BIOS CMOS Setup Utility
SOYO COMBO Feature PC Health Status
Standard CMOS Features Load Fail - Safe Defaults
Advanced BIOS Features Load Optimized Defaults
Advanced Chipset Features Set Supervisor Password
Integrated Peripherals Set User Password
Power Management Setup Save & Exit Setup
PnP/PCI Configurations Exit Without Saving
Esc : Quit : Select Item
F10 : Save & Exit Setup
Change CPU’s Clock & Voltage
2-3 QUICK BIOS SETUP
This Motherboard does not use any hardware jumpers to set the CPU
frequency. Instead, CPU settings are software configurable with the BIOS
[SOYO COMBO FEATURE]. The [SOYO COMBO FEATURE]
combines the main parameters that you need to configure, all in one menu,
for a quick setup in BIOS.
After the hardware installation is complete, turn the power switch on, then
press the <DEL> key during the system diagnostic checks to enter the
Award BIOS Setup program. The CMOS SETUP UTILITY will be shown
on the screen. Then, follow these steps to configure the CPU settings.
