ASUS M2NBP-VM CSM 2-33
2.5.4 Hardware Monitor
The items in this sub-menu displays the hardware monitor values automatically
detected by the BIOS. It also allows you to change CPU Q-Fan feature-related
parameters. Select an item then press to display the configuration options.
Q-Fan Controller [Disabled]
Allows you to enable or disable the Q-Fan controller.
Configuration options: [Disabled] [Enabled]
Vcore Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage
The onboard hardware monitor automatically detects the voltage output through
the onboard voltage regulators.
Configuration options: [xxx] [Ignored]
CPU Temperature, M/B Temperature
The onboard hardware monitor automatically detects and displays the motherboard
and CPU temperatures. These items are not user-configurable.
CPU Fan Speed [xxxxRPM]
Chassis Fan1/Fan2 Speed [xxxxRPM]
Power Fan Speed [xxxxRPM]
The onboard hardware monitor automatically detects and displays the CPU,
Chassis, and chip fan speeds in rotations per minute (RPM). If any of the fans is
not connected to the motherboard, the field shows 0. These items are not user-
configurable.
CPU Fan Speed warning [800 RPM]
Sets the CPU fan speed warning feature.
Configuration options: [Disabled] [800RPM] [1200RPM] [1600RPM]
Select Menu
Item Specific Help
Press [Enter] to
enable or disable
Hardware Monitor
Q-Fan Controller [ Disabled ]
