2-22 Chapter 2: BIOS setup
Select Menu
Item Specific Help
DRAM timing and control
Phoenix-Award BIOS CMOS Setup Utility
Advanced
AI NET2
POST Check LAN Cable [Enabled]
Pair Status Length
LAN1(1-2) Open N/A
LAN1(3-6) Open N/A
LAN1(4-5) Open N/A
LAN1(7-8) Open N/A
2.4.2 AI Net2
POST Check LAN Cable [Enabled]
Enables or disables checking of the LAN/LAN2 cable during the Power-On Self-
Test (POST). Configuration options: [Disabled] [Enabled]
DRAM Configuration
The items in the sub-menu show the DRAM-related information auto-detected by
the BIOS.
2.4.3 CPU Configuration
Select Menu
Item Specific Help
DRAM timing and control
Phoenix-Award BIOS CMOS Setup Utility
Advanced
CPU Configuration
CPU Type AMD Engineering Sample
CPU Speed 2600MHz
Cache RAM 1024K
DRAM Configuration
AMD Live! [Disabled]
AMD Cool’n’Quiet Function [Disabled]
CPU VID Code Voltage 1.400V
Select Menu
Item Specific Help
Setting platform
Memclock or limit
value.
Phoenix-Award BIOS CMOS Setup Utility
Advanced
Memory Clock Frequency [Auto]
Tcl [Auto]
Trcd [Auto]
Trp [Auto]
Tras [Auto]
Trc [Auto]
Trwt [Auto]
1T/2T Memory Timing [Auto]
Memory Hole Remapping [Enabled]
Bottom of 32-bit[31:24] IO space [E0]
Bottom of UMA DRAM [31:24] [FC]
DRAM MCE enable [Disabled]
Chip-Kill mode enable [Enabled]
DRAM ECC Redirection [Enabled]
DRAM background scrubber [Disabled]
L2 cache background scrubber [Disabled]
DCache background scrubber [Disabled]
DRAM Configuration
