Chapter 2 48
Advanced
The Advanced screen contains parameters involving your hardware devices. It also provides advanced
settings of the system.
FIR Ports
Configure the system’s infrared port using options: Disabled and Enabled.
The table below describes the parameters in the screen. Settings in boldface are the default and suggested
parameter settings.
Description Option
FIR I/O Settings Sets the base I/O address and IRQ for
Infrared port. COM1, 3F8, IRQ4/ COM2,
2F8, IRQ3/ COM3, 3E8,
IRQ4/ COM4, 2E8, IRQ3
DMA Setting for Fast
IR Sets a DMA channel for the printer to
operate in ECP mode. This parameter is
enabled only if Mode is set to ECP. DMA1, DMA2, DMA3,
Mode Setting Normak (16550), IrDA
(HPSIR), ASK IR, FAST IR
Insyde Software SCU May 20, 2003 5:40:09
Main Advanced Security Boot Exit
---------------------------------FIR Ports--------------------------------
-----FIR I/O settings--- -Mode Setting for IRDA-
Infrared Ports (FIR)
( ) Disabled ( ) Normal (16550)
( ) COM1,3F8,IRQ4 ( ) IrDA (HPSIR) Parallel Port(LPT)
( ) COM2,2F8,IRQ3 ( ) ASK IR
( ) COM3,3E8,IRQ4 ( Ԧ) FAST IR ԩLegacy U SB support
( Ԧ) COM4,2E8,IRQ3
--DMA Setting For Fast IR--
( ) DMA1
( ) DMA2
( ) DMA3
OK Cancel
for block select. for item select.
< Enter> for accept. for reject. activates accelerators.
for Enable or Disable.
