6 Chapter 1
Item Description Item Description
JP1 RJ11/RJ45 Connector JP20 Int. K/B Connector
JP2 CRT Connector JP21 Bluetooth Connector
JP3 Printer Connector JP22 DDR SODIMM Socket
JP4 TV-Out Connector JP23 ODD Connector
JP5 USB Connector JP24 T/P Board Connector
JP6 USB Connector JP25 HDD Connector
JP7 USB Connector JP27 MINIPCI Connector
JP8 IEEE 1394 Connector JP29 DDR SODIMM Socket
JP9 Power Board Connector PCN2 AC Jack Connector
JP10 MDC Cable Connector PCN3 Battery Connector
JP11 LCD Connector U4 LAN Chip
JP12 Cardbus Connector U11 North Bridge Chip
JP13 FAN Connector U12 VGA Chip
JP14 MDC Connector U14 South Bridge Chip
JP15 Right Speaker Connector U16 CPU Socket
JP16 Left Speaker Connector U31 FIR
JP17 Subwoofer Connector U40 BIOS ROM
JP18 LCM Connector U45 Cardbus Controller
JP19 SD Board Connector T1 LAN Transformer
