Chapter 2 Basic Operation

2-9

7. Hold the green grip (on the middle of Guide Plate) (8) and turn the Guide Plate towards the
outside. While holding the green grip, again rotate Feed Knob (7) until 8.5” (210mm) of the
leading edge comes out.

8. Slide the green Cutter Knob (9) fully from one side to the other to make a new straight edge.
Remove the cut portion.

9. Close Roll Deck.

NOTE

Be sure to close the Roll Deck fully until it locks at the correct position.
A paper jam may occur if it is not locked firmly.

NOTE

Completely slide Cutter Knob until it stops at either end.
Not doing so may cause a paper jam.

Leading edge
