American Standard 2651.110.WXX User Manual
Page 2
26” x 51” Walk-In
Soaking Tub, Air Spa And Whirlpool
High Gloss
GENERAL SPECIFICATIONS FOR 2651.110.XXX
WALK-IN BATH TUB
INSTALLED SIZE___________51 x 26-1/4 x 37-1/2 In. (1295 x 665 x 950 mm)
WEIGHT _____________________________________________175 Lbs. (79 kg)
WEIGHT w/ WATER __________________________________550 Lbs. (250 kg)
OPERATING GAL. _____________________________________45 Gal. (170 L.)
FLOOR LOADING _______________________59 Lbs/Sq. Ft (289 Kgs/Sq. m.)
(PROJECTED AREA)
CUBE (FT³) _______________________________________________________29
NOTES:
TUB IS SUPPORTED BY THE FRAME AND FIVE
INTEGRATED ADJUSTABLE FEET, NO ADDITIONAL
SUPPORT IS REQUIRED.
REFER TO INSTALLATION INSTRUCTIONS SUPPLIED
WITH TUB FOR ADDITIONAL INFORMATION.
FIXTURES NOT INCLUDED AND MUST BE ORDERED
SEPARATELY.
PROVIDE SUITABLE REINFORCEMENT TO SUB
FLOOR FOR ALL SUPPORTS.
IMPORTANT:
Dimensions of fixtures are nominal, may vary and are
subject to change or cancellation. No responsibility is
assumed for use of
superseded or voided leaflet
