A
mt
ÙUW SktildmC
HEATER
BLANK
DISCHARGE
TEE
PUMP
DISCHARGE
COUPLING
1" RIGID
PVC TUBING
REMINISCENCE
DROP-IN ELITE
WHIRLPOOL
Model No. 2908E
1/2" RIGID
PV
CTUB
|
N
G
je
FLEO
d
Y
ASSEMBLY
* ★
DESCRIPTION
PART NUMBER
PKG QTY
Pump Suction Coupling
0471S6-0070A
1
O-Ring
0471S7-0070A
1
Pump Discharge Coupling
0471S6-0070A
1
★ Silent Air Control Valve
752S55-XXX0A
1
★ Flex Jet Nozzle Assembly A
752S51-XXX0A
1
★ Flex Jet Escutcheon Assembly o
752S50-XXX0A
1
Flex Jet Body Assembly
752S49-0070A
1
★ Idealflow Nozzle Assembly
752407-XXX0A
1
★ Idealflow Escutcheon Assembly
75240S-XXX0A
1
Idealflow Body Assembly
752409-0070A
1
♦ Suction Guard
047463-XXX0A
1
★ Suction Fitting
047550-XXX0A
1
Suction Fitting Elbow
7511S6-0070A
1
★ Discharge Tee
04743S-0070A
1
Pump w/Air Switch (1.6 H.P.]
752S56-0070A
1
Air Switch
7523SS-0070A
1
★ Air Actuator Cap and Body
752439-XXX0A
1
Air Actuator Tubing
047602-0070A
3 ft.
Safety Suction Device 6 Lb.
752205-1010A
1
NOTE:
Schedule 40 Rigid PVC Piping available through local plumbing supply outlets.
★ Replace XXX with Fixture Color Code, YYY with Trim Finish
o
Removal/installation requires tool part no.
Removal/installation requires tool part no.
752905- 0070A
752906- 0070A
