COLONY 5’™
WHIRLPOOL AND BATHING POOL
HIGH GLOSS ACRYLIC
COLONY 5’ WHIRLPOOL AND BATHING POOL
❏
2675.018 Whirlpool featuring System I:
• Acrylic with fiberglass reinforcement
• Dual, molded-in armrests at lumbar area
• 1.0 HP single speed, self-draining pump/motor
with dry run seal
• Factory installed power cord with plug
• Six multi-directional and individually flow-rate
adjustable color-coordinated jets
• Deck-mounted, color-coordinated air switch
On/Off control
• Single, color-coordinated air volume control
• Factory installed and tested whirlpool system
❏
2675.018C Stay Clean™ Whirlpool Massage
Featuring System I:
• Same as 2675.018 except with the
StayClean™ whirlpool system featuring
Antimicrobial AlphaSan®
❏
2675.002 Bathing Pool
• Same as above without whirlpool system
Nominal Dimensions: 1524 x 832 x 502mm
(5’ x 32-3/4” x 19-3/4")
© 2003 American Standard Inc.
BV-32
Revised 1/99
To Be Specified - Required:
❏ Color:
❏ Bath Faucet: (specify finish)
❏ Bath Drain: 1583.470 (specify finish)
To Be Specified - Optional:
❏ 5 Foot Acrylic Apron: 9260.018 (specify color)
❏ 5 Foot Apron: 9360.018 (specify color)
❏ Grab Bar Kit: 9822.200-two per kit (specify finish)
❏ Jet Trim Ring Kit: 9860.200-two per kit (specify finish)
❏ Universal Tile Bead Kit: 751755-100
NOTE: Roughing-in dimensions and product
specifica-tions shown on reverse side of page.
Compliance Certifications -
Meets or Exceeds the Following Specifications:
• Underwriters Laboratories - Hydromassage
Bathtubs UL 1795
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
For color/finish availability and other faucet choices,
please see the Product Selector and Pricing Guide.
