rePaIr ParTs For 45-0456 44" lawnsweePer
reF QTY ParT no DesCrIPTIon
1 1 42020 Bag Frame Tube
2 1 41041 Pivot Rod
3 1 40890 Hopper Bag
4 2 26414 Bag Arm Channel
5 1 40989 Dump Tube
6 2 40892 Upper Hopper Tube
7 2 43938 Hopper Support Rod
8 2 26408 Drawbar Bracket
9 1 40894 Handle Tube
10 2 40897 Lower Hopper Tube
11 2 40893 Rear Hopper Tube
12 1 23014 Hitch Bracket
13 1 24192 Straight Hitch Bracket
14 1 26413 Drawbar
15 7 44292 Hex Bolt, 5/16-18 x 2-1/2"
16 1 43648 Hex Bolt, 1/4-20 x 1-1/2"
17 4 43182 Hex Bolt, 5/16-18 x 3/4"
18 1 43343 Hair Cotter Pin, 3/32 x 2-5/16"
19 3 43055 Hair Pin, 3/32 x 1.8"
20 1 47623 Hitch Pin, 3/8 x 3"
21 9 47810 Nylock Nut, 5/16-18
22 2 23368 Spacer, .76 x 1 x .76"
23 2 44917 Palnut, 3/8"
24 18 47189 Nylock Nut, 1/4"
25 2 712-3046 Jam Nut, 5/16-18
26 5 43978 Curved Head Bolt, 1/4-20 x 1"
27 2 43501 Cotter Pin, 9/64 x 1-1/2"
28 2 48365 Clevis Pin, 1/4 x 1.11"
29 1 7071 Handle Grip 3/4"
30 2 26484 Pivot Rod Retainer
31 2 712-0421 Plastic Wing Nut, 5/16"
reF QTY ParT no DesCrIPTIon
32 2 41036 Compression Spring
33 1 41013 Dump Handle Clip
34 1 23878 U-Clamp
35 1 23353 Hitch Pin, 3/8 x 3"
36 1 68167 Sweeper Housing
37 1 66240 Height Adjustment Tube
38 1 40891 Height Adjustment Knob
39 2 26538 Step Spacer, .41 x .75"
40 2 41035 Dust Cover
41 2 42093 Washer, .59 x .75 x .025"
42 4 48840 Screw, 1/4-20 x 1/2"
43 2 41012 Bushing
44 1 40722 42" Brush Shaft
45 4 44007 Shim Washer
46 2 47046 Dowel Pin, 1/4 x 3/4"
47 1 48652 Pinion Gear (RH)
48 1 48651 Pinion Gear (LH)
49 2 42094 Retaining Ring
50 2 44008 Washer, .78 x 1.125 x .025
51 2 141 Washer, .378 x 1.25 x .061
52 2 41017 Hub Cap
53 2 44961 Hex Bolt, 3/8-24 x 3-1/4"
54 2 1038 Nylock Jam Nut, 3/8"
55 2 40987 Wheel
56 4 43661 Hex Bolt, 1/4-20 x 1"
57 8 43012 Hex Bolt, 1/4-20 x 3/4"
58 4 46780 42" Sweeper Brush
59 4 23580 Brush Retainer (Double)
60 8 23581 Brush Retainer (Single)
61 2 1540-31 Washer, .78 x 1.25 x .062
1 42016 Owners Manual
