v
To
help
ensure
signal
quality,
do
not
mix
drives
with
different
speeds
and
data
rates.
v
To
update
the
firmware
and
BIOS
code
for
an
optional
ServeRAID
SAS
controller,
you
must
use
the
IBM
ServeRAID
Support
CD
that
comes
with
the
ServeRAID
option.
Use
the
RAID
Configuration
Utility
programs
to
perform
the
following
tasks:
v
Configure
a
redundant
array
of
independent
disks
(RAID)
array
v
View
or
change
the
RAID
configuration
and
associated
devices
Starting
the
RAID
Configuration
Utility
program
To
start
the
RAID
Configuration
Utility
program,
complete
the
following
steps:
1.
Turn
on
the
server.
2.
When
the
prompt
<<<
Press
for
IBM
ServeRAID
Configuration
Utility!
>>>
appears,
press
Ctrl+A.
If
you
have
set
an
administrator
password,
you
are
prompted
to
type
the
password.
3.
To
select
a
choice
from
the
menu,
use
the
arrow
keys.
4.
Use
the
arrow
keys
to
select
the
channel
for
which
you
want
to
change
settings.
5.
To
change
the
settings
of
the
selected
items,
follow
the
instructions
on
the
screen.
Be
sure
to
press
Enter
to
save
your
changes.
RAID
Configuration
Utility
menu
choices
The
following
choices
are
on
the
RAID
Configuration
Utility
menu:
v
Array
Configuration
Utility
Select
this
choice
to
create,
manage,
or
delete
arrays,
or
to
initialize
drives.
v
SerialSelect
Utility
Select
this
choice
to
configure
the
controller
interface
definitions
or
to
configure
the
physical
transfer
and
SAS
address
of
the
selected
drive.
v
Disk
Utilities
Select
this
choice
to
format
a
disk
or
verify
the
disk
media.
Select
a
device
from
the
list
and
read
the
instructions
on
the
screen
carefully
before
making
a
selection.
Using
the
baseboard
management
controller
The
baseboard
management
controller
provides
basic
service-processor
environmental
monitoring
functions
for
the
server.
If
an
environmental
condition
exceeds
a
threshold
or
if
a
system
component
fails,
the
baseboard
management
controller
lights
LEDs
to
help
you
diagnose
the
problem
and
also
records
the
error
in
the
BMC
system
event
log.
The
baseboard
management
controller
also
provides
the
following
remote
server
management
capabilities:
v
Command-line
interface
(IPMI
Shell)
The
command-line
interface
provides
direct
access
to
server
management
functions
through
the
IPMI
protocol.
Use
the
command-line
interface
to
issue
commands
to
control
the
server
power,
view
system
information,
and
identify
the
server.
You
can
also
save
one
or
more
commands
as
a
text
file
and
run
the
file
as
a
script.
v
Serial
over
LAN
44
ThinkServer
RD120
Types
6444,
6445,
6446,
and
6447:
Installation
Guide
