Contents viii
4 Configuring the system 35
Upgrading the system 37
Installation precautions 38
ESD precautions 38
Preinstallation instructions 39
Post-installation instructions 39
Opening the server 40
Before opening the server 40
To remove the side panel 41
To remove the front panel 42
Installing and removing storage devices 43
To install a 5.25-inch storage device 43
Upgrading the CPU 45
To remove a CPU with heatsink 45
To install a CPU with heatsink 47
Upgrading the system memory 49
Memory configuration 49
To remove a DIMM 50
To install a DIMM 51
Reconfiguring the system memory 51
Installing an expansion card 52
To install an expansion card 52
Installing and removing a hard disk 55
To remove a hard disk 55
To install a hard disk 56
Configuring the SCSI/SCSI RAID HBA 57
How to use SCSI HBA setup utility 57
Loading HBA Default Settings 57
How to use SCSI RAID HBA setup utility 57
How To Create RAID 1 (Mirror) volume
with a Hot Spare Disk
57
RAID Volume Initialization 58
Exit and Restart the server 58
MegaRAID Configuration Utility 59
Load RAID Card Default Setting 59
Create RAID1 Volume 59
Assign Hot Spare Disk 60
Initialize RAID Volume 60
Save And Exit MegaRAID Configuration Utility 60
Configuring Parallel ATA and Serial ATA devices 61
ATA Operate Mode 61
Intel ICH5R Serial ATA RAID introduction 62
Parallel ATA and Serial ATA device configurations
supported by Intel ICH5R
62
